| Air flow at 1 speed - extractor by EN 61591 251 m3/h |
Air flow at 2 speed - extractor by EN 61591 335 m3/h |
Air flow at 3 speed - extractor by EN 61591 385 m3/h |
| Air Flow at Maximum Speed in Normal Use [Intensive or Boost Excluded] 385 m3/h |
Air Flow at Minimum Speed in Normal Use 251 m3/h |
Air Flow Rate at Best Efficiency Point - Q BEP 206.8 m3/h |
| Air Pressure at Best Efficiency Point P BEP 183 Pa |
Annual energy consumption 60.7 kWh |
Average Illumination of the Lighting System on the Cooking Surface - E middle 263 lux |
| Control panel on one side/two sides One side |
Country of Origin on Rating Label Made in EU |
Dimensions of grease filter 222.5 x 250 x 9 mm |
| Display color Red |
Distance from light cover to wall 28 mm |
Distance to electric hob 450 mm |
| Distance to gas hob 650 mm |
Electric Power Input at Best Efficiency Point - W BEP 95.8 W |
Fluid Dynamic Efficiency - FDE hood 11 |
| Fluid Dynamic Efficiency Class E |
Grease Filtering Efficiency - GFE hood 67.3 % |
Grease Filtering Efficiency Class D |
| Internal/external motor Internal |
Lighting Efficiency - LE hood 40.5 lux/W |
Lighting Efficiency Class A |
Lighting Efficiency Class A |
Maximum Possible Air Flow 385 m3/h |
Motor unit rated power 120 W |
Motor type/model K-42 010 02 HE CW |
Net depth 375 mm |
Net height max 1330 mm |
Net height min 955 mm |
Net weight 9.36 kg |
Net width 600 mm |
Noise level at 1 speed - extractor by EN 60704-2-13 58 dB |
Noise level at 2 speed - extractor by EN 60704-2-13 61 dB |
Noise level at 3 speed - extractor by EN 60704-2-13 65 dB |
Nominal Power of the Lighting System - W L 6.5 W |
Number of motor units 1 |
Number units of main lighting 2 |
Air exhaust diameter 150 mm |
Type of plug or cable Euro plug |
Power Consumption in Standby Mode - Ps 0.25 W |
Power cabel length 170 cm |
Power rating 126 W |
Power Supply Voltage 230V |
Power unit of main lighting 3 W |
Sound Power Emission at Maximum Speed Available in Normal Use [Intensive or Boost Excluded] 65 dB |
Sound Power Emission at Minimum Speed Available in Normal Use 58 dB |
Noise level 65 dB |
Time Increase Factor - f 1.6 |
Type of main lighting LED |
