Specification

FEATURES

Air flaps Yes Delay Yes FrameOn Yes
Maximum time of delay 15 ' Montage template Yes Panel - language version Pictograms
Protection class of electric shock I_Class Type of work Extraction/Recirculation

Equipment

Gesture control Yes Number of carbon filters 2 Number of grease filters 1
Number of layers in grease filter 5 Number of speed 4 Type of control Sensor
Type of display LCD Type of grease filters Aluminium frame Carbon filter type FWP 18

Technical data

Frequency 50 Air flow at 1 speed - extractor by EN 61591 382 m3/h Air flow at 2 speed - extractor by EN 61591 476 m3/h
Air flow at 3 speed - extractor by EN 61591 619 m3/h Air flow at 4 speed - extractor by EN 61591 700 m3/h Air Flow at Intensive or Boost Setting [If Available] 700 m3/h
Air Flow at Maximum Speed in Normal Use [Intensive or Boost Excluded] 619 m3/h Air Flow at Minimum Speed in Normal Use 382 m3/h Air Flow Rate at Best Efficiency Point - Q BEP 364 m3/h
Air Pressure at Best Efficiency Point P BEP 408.6 Pa Annual energy consumption 49.1 kWh Average Illumination of the Lighting System on the Cooking Surface - E middle 123.6 lux
Container qty 40'HQ 276 Control panel on one side/two sides One side Country of Origin on Rating Label Made in PRC
Dimensions of grease filter 297x262 mm Display color Red Distance from light cover to wall 36 mm
Distance to electric hob 450 mm Distance to gas hob 650 mm Electric Power Input at Best Efficiency Point - W BEP 137.1 W
Fluid Dynamic Efficiency - FDE hood 30.1 Fluid Dynamic Efficiency Class A Grease Filtering Efficiency - GFE hood 57 % Grease Filtering Efficiency Class E Intensive or Boost Setting Auto-Off time 5 ' Internal/external motor Internal Main lighting colour temperature [K] 6500 Lighting Efficiency - LE hood 22.5 lux/W Lighting Efficiency Class B Lighting Efficiency Class B Limitation of Exhaust Air - t limit 9 ' Maximum Possible Air Flow 700 m3/h Motor unit rated power 300 W Motor type/model E series Net depth 475 mm Net height max 1420 mm Net height min 940 mm Net weight 25.38 kg Net width 600 mm Noise level at 1 speed - extractor by EN 60704-2-13 59 dB Noise level at 2 speed - extractor by EN 60704-2-13 66 dB Noise level at 3 speed - extractor by EN 60704-2-13 68 dB Noise level at 4 speed - extractor by EN 60704-2-13 69 dB Nominal Power of the Lighting System - W L 5.5 W Number of motor units 1 Number units of decorative lighting 2 Number units of main lighting 1 Air exhaust diameter 150 mm Type of plug or cable Euro plug Power Consumption in Standby Mode - Ps 0.43 W Power Consumption in Off Mode - Po 0.23 W Power cabel length 120 cm Power rating 308 W Power Supply Voltage 230V Power unit of decorative lighting 2 W Power unit of main lighting 4 W Sound Power Emission at Intensive or Boost Setting [if available] 69 dB Sound Power Emission at Maximum Speed Available in Normal Use [Intensive or Boost Excluded] 68 dB Sound Power Emission at Minimum Speed Available in Normal Use 59 dB Noise level 68 dB Time Increase Factor - f 0.9 Type of main lighting LED panel
