Carbon filters : 3
Clean and efficient air extraction through integrated carbon filters.
(* carbon filter sold separately) -
LED display
It takes just a glance at the control display to check the hood setting, including the fan speed level and the remaining time left to run. Most models do not even require us to check when the filters need cleaning or changing - the filter indicators simply tell us when.
-
LED lighting
Low light makes kitchen work much more difficult. The same goes for light bulbs that constantly burn out. To guarantee ease of use, Hansa hoods are equipped with an innovative energy-efficient LED lighting system. The LED lights are highly durable, and emit a bright and pleasant light which isn’t tiring for the eyes. Choose the Hansa hood, and enjoy the best solutions!
-
Sensor control system
Forget about cleaning the dirt which gathers around the buttons! The Hansa hoods feature touch panels located under a glass cover. With this, you can quickly and easily clean the panel, as well as have easy access to all hood functions. See how addictive can convenience be!
OKC 901 UBH
OKC IN 900 BT
-
Carbon filters : 3
-
LED display
-
LED lighting
-
Sensor control system
-
FEATURES
- Accessories -
- Air flaps Yes
- Delay Yes
- Maximum time of delay 10 '
- Panel - language version Pictograms
- Protection class of electric shock I_Class
- Type of work Extraction/Recirculation
-
Equipment
- Number of carbon filters 3
- Number of grease filters 3
- Number of layers in grease filter 5
- Number of speed 4
- Type of control Sensor
- Type of grease filters Aluminium frame
- Carbon filter type FWK 280
-
Technical data
- Air flow at 1 speed - extractor by EN 61591 276 m3/h
- Air flow at 2 speed - extractor by EN 61591 358 m3/h
- Air flow at 3 speed - extractor by EN 61591 457 m3/h
- Air flow at 4 speed - extractor by EN 61591 711 m3/h
- Air Flow at Intensive or Boost Setting [If Available] 711 m3/h
- Air Flow at Maximum Speed in Normal Use [Intensive or Boost Excluded] 457 m3/h
- Air Flow at Minimum Speed in Normal Use 276 m3/h
- Air Flow Rate at Best Efficiency Point - Q BEP 358.5 m3/h
- Air Pressure at Best Efficiency Point P BEP 403 Pa
- Annual energy consumption 64.5 kWh
- Average Illumination of the Lighting System on the Cooking Surface - E middle 277 lux
- Control panel on one side/two sides One side
- Country of Origin on Rating Label Made in Poland
- Dimensions of grease filter 222.5 x 250 x 9 mm
- Display color Red
- Distance from light cover to wall 400 mm
- Distance to electric hob 450 mm
- Distance to gas hob 650 mm
- Electric Power Input at Best Efficiency Point - W BEP 153.1 W
- Fluid Dynamic Efficiency - FDE hood 28.2
- Fluid Dynamic Efficiency Class A
- Grease Filtering Efficiency - GFE hood 68.9 %
- Grease Filtering Efficiency Class D
- Intensive or Boost Setting Auto-Off time 5 '
- Internal/external motor Internal
- Lighting Efficiency - LE hood 21.3 lux/W
- Lighting Efficiency Class B
- Lighting Efficiency Class B
- Limitation of Exhaust Air - t limit 8 '
- Maximum Possible Air Flow 711 m3/h
- Motor unit rated power 260 W
- Motor type/model S-45
- Net depth 485 mm
- Net height max 1057 mm
- Net height min 747 mm
- Net weight 20.1 kg
- Net width 900 mm
- Noise level at 1 speed - extractor by EN 60704-2-13 53 dB
- Noise level at 2 speed - extractor by EN 60704-2-13 57 dB
- Noise level at 3 speed - extractor by EN 60704-2-13 63 dB
- Noise level at 4 speed - extractor by EN 60704-2-13 69 dB
- Nominal Power of the Lighting System - W L 13 W
- Number of motor units 1
- Number units of main lighting 1
- Air exhaust diameter 150 mm
- Type of plug or cable Euro plug
- Power Consumption in Standby Mode - Ps 0.25 W
- Power cabel length 200 cm
- Power rating 273 W
- Power Supply Voltage 230V
- Power unit of main lighting 13 W
- Sound Power Emission at Intensive or Boost Setting [if available] 69 dB
- Sound Power Emission at Maximum Speed Available in Normal Use [Intensive or Boost Excluded] 63 dB
- Sound Power Emission at Minimum Speed Available in Normal Use 53 dB
- Noise level 63 dB
- Time Increase Factor - f 1
- Type of main lighting LED
